Reverse Proxy dengan OpenLiteSpeed

·3 mins·
Litespeed Litespeed
Table of Contents

OpenLiteSpeed dapat dikonfigurasi sebagai reverse proxy untuk meneruskan trafik ke server backend atau aplikasi yang berjalan pada layanan HTTP.

Contoh arsitektur reverse proxy.

flowchart LR
    subgraph "Reverse Proxy Flow"
        direction LR

        %% Nodes definition
        D1["user's device (D)
example.com"]
        D2["user's device (D)
example.com"]
        D3["user's device (D)
example.com"]

        Internet(("Internet"))

        E["reverse proxy (E)"]

        F1["origin server (F)"]
        F2["origin server (F)"]

        %% Connections
        D1 --> Internet
        D2 --> Internet
        D3 --> Internet
        Internet --> E
        E --> F1
        E --> F2

        %% Styling (Optional, to match the visual hierarchy)
        style Internet fill:#ffffff,stroke:#0000ff,stroke-width:2px
        style E fill:#ffffff,stroke:#0000ff,stroke-width:2px
        style F1 fill:#ffffff,stroke:#0000ff,stroke-width:2px
        style F2 fill:#ffffff,stroke:#0000ff,stroke-width:2px
    end

Install OpenLiteSpeed
#

Tambahkan repository resmi LiteSpeed:

curl -s https://repo.litespeed.sh | bash

Kemudian install OpenLiteSpeed:

yum -y install openlitespeed

Konfigurasi Reverse Proxy
#

Edit atau buat file virtual host, misalnya:

/usr/local/lsws/conf/vhosts/app3.example.com-443/vhost.conf

Kemudian tambahkan konfigurasi berikut.

docRoot                 /home/web1/public_html
vhAliases               *
listeners               app3.example.com-443
adminEmails             [email protected]

enableGzip              1
enableIpGeo             1

index {
  useServer             0
  indexFiles            index.php index.php8 index.php7 index.php5 index.perl index.pl index.plx index.ppl index.cgi index.jsp index.jp index.phtml index.shtml index.xhtml index.html index.htm index.js
  autoIndex             0
}

vhssl {
  keyFile                 /etc/letsencrypt/live/app3.example.com/privkey.pem
  certFile                /etc/letsencrypt/live/app3.example.com/fullchain.pem
  certChain               1

  sslProtocol             30
  enableSpdy              15

  sslSessionCache         1
  sslSessionTickets       1
  sslSessionTimeout       86400

  ocspEnable              1
  ocspRespMaxAge          86400
  ocspOverlapPeriod       3600

  quicEnable              1
  quicShmDir              /dev/shm

  sslCipherSuite          EECDH+AESGCM:EECDH+CHACHA20:!aNULL:!MD5:!DSS:!RSA
  sslCipherSuiteTLS13     TLS_AES_256_GCM_SHA384:TLS_CHACHA20_POLY1305_SHA256:TLS_AES_128_GCM_SHA256
}

errorlog /usr/local/lsws/logs/app3.example.com.err {
  useServer             0
  logLevel              ERROR
  rollingSize           10M
}

accesslog /usr/local/lsws/logs/app3.example.com.log {
  useServer             0
  logFormat             %h %l %u %t "%r" %>s %b "%{Referer}i" "%{User-Agent}i"
  logHeaders            5
  rollingSize           10M
  keepDays              10
  compressArchive       1
}

rewrite {
  enable                1
  autoLoadHtaccess      1

  RewriteRule ^/(.*) HTTP://30002//$1 [P,L,E=PROXY-HOST:app3.example.com]
}

websocket / {
  address               127.0.0.1:30002
}

scripthandler {
  add                   lsapi:php82 php
}

extprocessor php82 {
  type                  lsapi
  address               UDS://tmp/lshttpd/php82.sock
  maxConns              10

  env                   PHP_INI_SCAN_DIR=:/home/web1/public_html:/home/web1/php82
  env                   LSPHP_ENABLE_USER_INI=on
  env                   LSAPI_CHILDREN=10

  initTimeout           600
  retryTimeout          0
  persistConn           1
  pcKeepAliveTimeout    1
  respBuffer            0
  autoStart             2
  path                  /usr/local/apps/php82/bin/lsphp

  memSoftLimit          2047M
  memHardLimit          2047M
  procSoftLimit         400
  procHardLimit         500
}

extprocessor 30002 {
  type                  proxy
  address               127.0.0.1:30002

  maxConns              50
  initTimeout           30
  retryTimeout          0

  keepAlive             1
  keepAliveTimeout      30

  respBuffer            0
}

header {
  set Strict-Transport-Security "max-age=63072000; includeSubDomains; preload"
  set X-Frame-Options "SAMEORIGIN"
  set X-Content-Type-Options "nosniff"
  set Referrer-Policy "strict-origin-when-cross-origin"
  set Content-Security-Policy "upgrade-insecure-requests"
}

module cache {
  storagePath           /usr/local/lsws/cachedata/$VH_NAME
}

module mod_security {
  ls_enabled            0
}

module modpagespeed {
  ls_enabled            0
}

Menggunakan .htaccess untuk Reverse Proxy (Alternatif)
#

Anda dapat menggunakan aturan .htaccess seperti berikut:

RewriteEngine On
RewriteCond %{HTTPS} !=on
RewriteRule (.*) HTTP://127.0.0.1:30002/$1 [P,QSA,L,E=PROXY-HOST:app3.example.com]

Hubungkan ke Listener (Port 80/443)
#

Edit file /usr/local/lsws/conf/httpd_config.conf lalu tambahkan virtual host

virtualhost web1.example.com-80 {
  vhRoot                  /home/web1/
  configFile              $SERVER_ROOT/conf/vhosts/$VH_NAME/vhost.conf
  allowSymbolLink         1
  enableScript            1
  restrained              1
  setUIDMode              2
  user                    web1
  group                   web1
}

virtualhost web1.example.com-443 {
  vhRoot                  /home/web1/
  configFile              $SERVER_ROOT/conf/vhosts/$VH_NAME/vhost.conf
  allowSymbolLink         1
  enableScript            1
  restrained              1
  setUIDMode              2
  user                    web1
  group                   web1
}

listener default-192.168.244.5 {
  address                 [ANY]:80
  secure                  0
  map                     example.com, www.example.com, mail.example.com
  map                     web1.example.com-80
}

listener SSL-192.168.244.5 {
  address                 [ANY]:443
  secure                  1
  keyFile                 /path/to/certs/private.key
  certFile                /path/to/certs/bundle.crt
  certChain               1
  sslProtocol             30
  map                     example.com, www.example.com, mail.example.com
  map                     web1.example.com-443
}

Restart Gracefully
#

Restart OpenLiteSpeed

/usr/local/lsws/bin/lswsctrl restart

Load Balancing
#

OpenLiteSpeed juga dapat dikonfigurasi sebagai load balancing ke beberapa backend memakai extprocessor + loadBalancer.

Tambahkan extprocessor untuk masing-masing backend.

extprocessor backend1 {
  type                  proxy
  address               127.0.0.1:30001
  maxConns              20
}

extprocessor backend2 {
  type                  proxy
  address               127.0.0.1:30002
  maxConns              20
}

Lalu buat load balancer group.

extprocessor app_lb {
  type                  loadbalancer
  workers               backend1, backend2

  # Algoritma load balancing:
  # 0 = Round Robin (default)
  # 1 = Least Connections
  # 2 = Locality
  lbAlgo                1

  sessionSticky         1
  retryTimeout          1
  initTimeout           1
}

Rewrite ke load balancer.

rewrite {
  enable                1
  autoLoadHtaccess      1

  RewriteEngine On
  RewriteRule (.*) app_lb:$1 [P,QSA,L]
}

Backend akan dibagi otomatis (balanced) antara:

  • 127.0.0.1:30001
  • 127.0.0.1:30002
